AFS Flyer Front Wing 1500
- 1,500area, cm²
- 955span, mm
- 6.30aspect ratio
- Mid-lowaspect · AR 6.0 – 8.5
Family FLYER Chord 185 mm Brand’s category Entry Disciplines wing, sup Full carbon · 2026
The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest with a traced outline, the Duotone Free 1500 (#2), is already drawn over it. Select a numbered wing to draw it — up to three at a time.
Its 955 mm span is 15% narrower than typical for the area — the median across the 81 current wings within 10% of its size is 1,120 mm.
Closest wings from other brands
Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.
| Brand | Wing | Area cm² | Δ area | Aspect ratio | Δ AR | Span mm | Band |
|---|---|---|---|---|---|---|---|
| F-One | PHANTOM Carbon 1480 | 1,480 | -1.3% | 6.20 | -1.6% | 960 | Mid-low aspect |
| Duotone | Free 1500 | 1,500 | +0.0% | 6.00 | -4.8% | 950 | Low aspect |
| ENSIS | PACER Front Wing 1550 | 1,550 | +3.3% | 6.00 | -4.8% | 964 | Low aspect |
| KT Foiling | Instinct 1450 | 1,450 | -3.3% | 6.33 | +0.5% | 960 | Mid-low aspect |
| RRD | Blaze LTE Front Wing Y30 1550 | 1,550 | +3.3% | 6.00 | -4.8% | 975 | Low aspect |
| Axis | BSC (Broad Spectrum Carve) 970 | 1,572 | +4.8% | 6.27 | -0.5% | 970 | Mid-low aspect |
Specifications
| Family | FLYER |
|---|---|
| Size | 1500 |
| Area, cm² | 1,500 |
| Area basis | unknown |
| Span, mm | 955 |
| Chord, mm | 185 |
| Aspect ratio | 6.30 |
| Band | Mid-low aspect |
| Brand’s category | Entry |
| Disciplines | wing, sup |
| Construction | Full carbon |
| Model year | 2026 |
| Source | manufacturer |
The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.
Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
