RRD Universal Moonfish Front Wing Y30 1900

1,900area, cm²
1,350span, mm
9.60aspect ratio
Highaspect · AR 9.5 – 11.5

Family UNIVERSAL MOONFISH Chord 180 mm Brand’s category Downwind Disciplines downwind, pump, parawing, sup Full Carbon

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest, the Sabfoil Leviathan 1350, is already drawn over it. Select a numbered wing to draw it — up to three at a time.

5Code Foils Kanga Series Front Wing 1870no outlineSpecs · table ↓

RRD Universal Moonfish Front Wing Y30 1900 · 1,350 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ Sabfoil Leviathan 1350 · 1,350 mm

Its 1,350 mm span is 4% wider than typical for the area — the median across the 58 current wings within 10% of its size is 1,300 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the RRD Universal Moonfish Front Wing Y30 1900, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
Sabfoil	Leviathan 1350	1,870	-1.6%	9.75	+1.6%	1,350	High aspect
Sabfoil	Leviathan Blackbird The 1350	1,864	-1.9%	9.80	+2.1%	1,350	High aspect
GONG	Trail V3 XL	1,940	+2.1%	9.40	-2.1%	1,350	Mid aspect
Armstrong	APF (All-round Pump Foil) APF1880	1,880	-1.1%	9.20	-4.2%	1,302	Mid aspect
Code Foils	Kanga Series Front Wing 1870	1,870	-1.6%	9.10	-5.2%	1,300	Mid aspect
GONG	Trail V3 Atmo XXL (Team / Carbon HM)	1,950	+2.6%	10.10	+5.2%	1,400	High aspect

Specifications

Every figure is RRD's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	UNIVERSAL MOONFISH
Size	1900
Area, cm²	1,900
Area basis	unknown
Span, mm	1,350
Chord, mm	180
Aspect ratio	9.60
Band	High aspect
Brand’s category	Downwind
Disciplines	downwind, pump, parawing, sup
Construction	Full Carbon
Model year	—
Source	manufacturer

The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
