RRD Blaze LTE Front Wing Y30 1100

1,100area, cm²
835span, mm
6.00aspect ratio
Lowaspect · AR ≤ 6.0

Family BLAZE LTE Chord 165 mm Brand’s category All-round / freeride Disciplines wing, prone Hybrid Carbon

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest with a traced outline, the GONG X-Over V3 L (#2), is already drawn over it. Select a numbered wing to draw it — up to three at a time.

1F-One PHANTOM Carbon 1080no outlineSpecs · table ↓

RRD Blaze LTE Front Wing Y30 1100 · 835 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ GONG X-Over V3 L · 840 mm

The Blaze LTE Front Wing Y30 runs 6 sizes, 850–1,850 cm²; aspect ratio moves 6.0–6.5 across the range.

Its 835 mm span is 16% narrower than typical for the area — the median across the 123 current wings within 10% of its size is 1,000 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the RRD Blaze LTE Front Wing Y30 1100, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
F-One	PHANTOM Carbon 1080	1,080	-1.8%	5.90	-1.7%	800	Low aspect
GONG	X-Over V3 L	1,100	+0.0%	6.40	+6.7%	840	Mid-low aspect
GONG	X-Over V3 Atmo L	1,108	+0.7%	6.40	+6.7%	840	Mid-low aspect
Axis	BSC (Broad Spectrum Carve) 810	1,070	-2.7%	6.42	+7.0%	810	Mid-low aspect
Naish	Ultra Jet Front Wing 1050	1,050	-4.5%	5.90	-1.7%	785	Low aspect

Specifications

Every figure is RRD's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	BLAZE LTE
Size	1100
Area, cm²	1,100
Area basis	unknown
Span, mm	835
Chord, mm	165
Aspect ratio	6.00
Band	Low aspect
Brand’s category	All-round / freeride
Disciplines	wing, prone
Construction	Hybrid Carbon
Model year	—
Source	manufacturer

The brand publishes this aspect ratio, but its own span and area (span² ÷ area) give a figure 5–10% away. The published number is kept and marked.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
