Slingshot One-Lock Glide 1525

1,525area, cm²
1,169span, mm
9.00aspect ratio
Midaspect · AR 8.5 – 9.5

Family One-Lock Glide Brand’s category Glide / high aspect Disciplines wing, prone, wake, pump carbon · 2026

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest, the Axis Spitfire 1180, is already drawn over it. Select a numbered wing to draw it — up to three at a time.

2Unifoil Evolution 235no outline3Code Foils S Series Front Wing 1540Sno outlineSpecs · table ↓

Slingshot One-Lock Glide 1525 · 1,169 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ Axis Spitfire 1180 · 1,180 mm

The One-Lock Glide runs 7 sizes, 625–1,525 cm²; aspect ratio moves 8.4–9.0 across the range.

Its 1,169 mm span is 4% wider than typical for the area — the median across the 73 current wings within 10% of its size is 1,120 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the Slingshot One-Lock Glide 1525, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
Axis	Spitfire 1180	1,554	+1.9%	9.13	+1.4%	1,180	Mid aspect
Unifoil	Evolution 235	1,516	-0.6%	9.40	+4.4%	1,191	Mid aspect
Code Foils	S Series Front Wing 1540S	1,540	+1.0%	9.50	+5.6%	1,210	Mid aspect
GONG	Curve H V3 FG 3XL	1,520	-0.3%	8.40	-6.7%	1,130	Mid-low aspect
GONG	Fluid H V3 FG 3XL	1,460	-4.3%	8.40	-6.7%	1,110	Mid-low aspect
GONG	Fluid V3 Atmo 3XL (Team / Carbon HM)	1,460	-4.3%	8.70	-3.3%	1,120	Mid aspect
Sabfoil	Leviathan 1150	1,580	+3.6%	8.37	-7.0%	1,150	Mid-low aspect
GONG	Sirus V3 L	1,450	-4.9%	9.30	+3.3%	1,160	Mid aspect
Takoon	Pump One Front Wing 1600	1,600	+4.9%	9.15	+1.7%	1,210	Mid aspect

Specifications

Every figure is Slingshot's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	One-Lock Glide
Size	1525
Area, cm²	1,525
Area basis	unknown
Span, mm	1,169
Chord, mm	—
Aspect ratio	9.00
Band	Mid aspect
Brand’s category	Glide / high aspect
Disciplines	wing, prone, wake, pump
Construction	carbon
Model year	2026
Source	manufacturer · read 2026-08-13

The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
