Duotone Glide 2.0 SLS 1350

1,350area, cm²
1,160span, mm
9.90aspect ratio
Highaspect · AR 9.5 – 11.5

Family Glide Brand’s category Glide / high aspect Disciplines wing, downwind, pump SLS · 2025

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest, the GONG Trail V3 Atmo L (Team / Carbon HM), is already drawn over it. Select a numbered wing to draw it — up to three at a time.

3Unifoil Evolution 205no outline4Code Foils S Series Front Wing 1300Sno outlineSpecs · table ↓

Duotone Glide 2.0 SLS 1350 · 1,160 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ GONG Trail V3 Atmo L (Team / Carbon HM) · 1,170 mm

Its 1,160 mm span is 8% wider than typical for the area — the median across the 94 current wings within 10% of its size is 1,070 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the Duotone Glide 2.0 SLS 1350, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
GONG	Trail V3 Atmo L (Team / Carbon HM)	1,350	+0.0%	10.10	+2.0%	1,170	High aspect
Naish	Excalibur HA Front Wing 1344	1,344	-0.4%	10.20	+3.0%	1,170	High aspect
Unifoil	Evolution 205	1,323	-2.0%	9.40	-5.1%	1,113	Mid aspect
Code Foils	S Series Front Wing 1300S	1,300	-3.7%	9.50	-4.0%	1,115	Mid aspect
F-One	JAM HM Carbon 1400	1,400	+3.7%	10.30	+4.0%	1,200	High aspect
GONG	Veloce V3 Atmo XXL	1,300	-3.7%	10.10	+2.0%	1,150	High aspect
GONG	Veloce Free Fly (FF) V3 Atmo XXL	1,300	-3.7%	10.60	+7.1%	1,170	High aspect
F-One	EAGLE HM Carbon 1290	1,290	-4.4%	9.50	-4.0%	1,105	Mid aspect
Cabrinha	Fusion H-Series MkII H1300	1,300	-3.7%	9.14	-7.7%	1,090	Mid aspect

Specifications

Every figure is Duotone's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	Glide
Size	1350
Area, cm²	1,350
Area basis	unknown
Span, mm	1,160
Chord, mm	—
Aspect ratio	9.90
Band	High aspect
Brand’s category	Glide / high aspect
Disciplines	wing, downwind, pump
Construction	SLS
Model year	2025
Source	manufacturer

The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
