Takoon X-Glide V2 Front Wing 1450

1,450area, cm²
1,018span, mm
7.20aspect ratio
Mid-lowaspect · AR 6.0 – 8.5

Family X-Glide V2 Chord 184 mm Brand’s category All-round / freeride Disciplines wing, prone, sup, pump, downwind

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest, the Axis PNG (Pump and Glide) 1010, is already drawn over it. Select a numbered wing to draw it — up to three at a time.

5ENSIS INFINITY ACE Front Wing 1390no outlineSpecs · table ↓

Takoon X-Glide V2 Front Wing 1450 · 1,018 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ Axis PNG (Pump and Glide) 1010 · 1,010 mm

The X-Glide V2 Front Wing runs 4 sizes, 1,050–1,700 cm², and holds its proportions across the range: every size publishes an aspect ratio within 5% of the others.

Its 1,018 mm span is 8% narrower than typical for the area — the median across the 76 current wings within 10% of its size is 1,112 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the Takoon X-Glide V2 Front Wing 1450, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
Axis	PNG (Pump and Glide) 1010	1,430	-1.4%	7.13	-1.0%	1,010	Mid-low aspect
GONG	Ascent V3 XXL	1,500	+3.4%	7.00	-2.8%	1,020	Mid-low aspect
AFS	Evo Front Wing 1450	1,450	+0.0%	7.60	+5.6%	1,040	Mid-low aspect
Axis	HPS (High Performance Speed) 1050	1,502	+3.6%	7.55	+4.9%	1,050	Mid-low aspect
ENSIS	INFINITY ACE Front Wing 1390	1,390	-4.1%	7.50	+4.2%	1,020	Mid-low aspect

Specifications

Every figure is Takoon's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	X-Glide V2
Size	1450
Area, cm²	1,450
Area basis	unknown
Span, mm	1,018
Chord, mm	184
Aspect ratio	7.20
Band	Mid-low aspect
Brand’s category	All-round / freeride
Disciplines	wing, prone, sup, pump, downwind
Construction	—
Model year	—
Source	manufacturer

The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
