Levitaz Front Wing FS 900
- 900area, cm²
- 1,100span, mm
- 13.30aspect ratio
- Very highaspect · AR 11.5 – 15.0
Family Free Series Brand’s category All-round / freeride Disciplines downwind, pump HM carbon with integrated titanium interface · 2026
The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest, the GONG Veloce HDW V3 M, is already drawn over it. Select a numbered wing to draw it — up to three at a time.
The Free Series runs 4 sizes, 540–900 cm², and changes proportion as it grows: aspect ratio runs 8.4 at one end of the range to 13.3 at the other, so its sizes differ in shape as well as in area.
Its 1,100 mm span is 24% wider than typical for the area — the median across the 131 current wings within 10% of its size is 890 mm.
Closest wings from other brands
Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.
| Brand | Wing | Area cm² | Δ area | Aspect ratio | Δ AR | Span mm | Band |
|---|---|---|---|---|---|---|---|
| GONG | Veloce HDW V3 M | 900 | +0.0% | 13.30 | +0.0% | 1,090 | Very high aspect |
| North | Sonar DW900 | 900 | +0.0% | 13.00 | -2.3% | 1,080 | Very high aspect |
| Axis | Fireball ULTRA 1070 | 877 | -2.6% | 13.07 | -1.7% | 1,070 | Very high aspect |
| GONG | Veloce Light Wind (LW) V3 Atmo M | 900 | +0.0% | 12.70 | -4.5% | 1,070 | Very high aspect |
| AFS | Ultra Front Wing 900 | 900 | +0.0% | 14.00 | +5.3% | 1,120 | Very high aspect |
| Armstrong | DWP (Downwind Performance) DWP930 | 930 | +3.3% | 13.00 | -2.3% | 1,100 | Very high aspect |
| Armstrong | UHA (Ultra High Aspect) UHA870 | 870 | -3.3% | 12.60 | -5.3% | 1,047 | Very high aspect |
| KT Foiling | Solus 930 | 930 | +3.3% | 14.00 | +5.3% | 1,140 | Very high aspect |
| Unifoil | Quest 135 | 870 | -3.3% | 13.40 | +0.8% | 1,078 | Very high aspect |
| Naish | SHA Foil Front Wing 933 | 933 | +3.7% | 12.97 | -2.5% | 1,100 | Very high aspect |
| GONG | Veloce DW V3 Atmo M | 900 | +0.0% | 14.10 | +6.0% | 1,130 | Very high aspect |
| Duotone | Hyperglide D/LAB 880 | 880 | -2.2% | 14.20 | +6.8% | 1,130 | Very high aspect |
| Code Foils | R Series Front Wing 860R | 860 | -4.4% | 13.00 | -2.3% | 1,050 | Very high aspect |
Specifications
| Family | Free Series |
|---|---|
| Size | FS 900 |
| Area, cm² | 900 |
| Area basis | unknown |
| Span, mm | 1,100 |
| Chord, mm | — |
| Aspect ratio | 13.30 |
| Band | Very high aspect |
| Brand’s category | All-round / freeride |
| Disciplines | downwind, pump |
| Construction | HM carbon with integrated titanium interface |
| Model year | 2026 |
| Source | manufacturer · read 2026-09-14 |
The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.
Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
