AFS Enduro Front Wing 1300

1,300area, cm²
1,190span, mm
11.00aspect ratio
Highaspect · AR 9.5 – 11.5

Family ENDURO Chord 149 mm Brand’s category Downwind Disciplines downwind, wing, parawing, pump, sup HR Carbon / Corecell · 2026

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest, the Axis ART PRO 1201, is already drawn over it. Select a numbered wing to draw it — up to three at a time.

6RRD Universal Moonfish Front Wing Y30 1350no outlineSpecs · table ↓

AFS Enduro Front Wing 1300 · 1,190 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ Axis ART PRO 1201 · 1,201 mm

The Enduro Front Wing runs 7 sizes, 600–1,300 cm², and holds its proportions across the range: every size publishes an aspect ratio within 5% of the others.

Its 1,190 mm span is 14% wider than typical for the area — the median across the 104 current wings within 10% of its size is 1,040 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the AFS Enduro Front Wing 1300, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
Axis	ART PRO 1201	1,318	+1.4%	11.14	+1.3%	1,201	High aspect
GONG	Veloce Free Fly (FF) V3 Atmo XXL	1,300	+0.0%	10.60	-3.6%	1,170	High aspect
KT Foiling	Atlas 1340	1,340	+3.1%	11.10	+0.9%	1,220	High aspect
Armstrong	APF (All-round Pump Foil) APF1350	1,350	+3.8%	10.70	-2.7%	1,202	High aspect
GONG	Hyper Trail V3 Atmo XL	1,250	-3.8%	11.40	+3.6%	1,190	High aspect
RRD	Universal Moonfish Front Wing Y30 1350	1,350	+3.8%	10.70	-2.7%	1,200	High aspect
Naish	Excalibur HA Front Wing 1344	1,344	+3.4%	10.20	-7.3%	1,170	High aspect

Specifications

Every figure is AFS's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	ENDURO
Size	Enduro 1300
Area, cm²	1,300
Area basis	unknown
Span, mm	1,190
Chord, mm	149
Aspect ratio	11.00
Band	High aspect
Brand’s category	Downwind
Disciplines	downwind, wing, parawing, pump, sup
Construction	HR Carbon / Corecell
Model year	2026
Source	manufacturer

The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
