Unifoil Quest 160

1,032area, cm²
1,175span, mm
13.40aspect ratio
Very highaspect · AR 11.5 – 15.0

Family Quest Chord 113 mm Brand’s category Downwind Disciplines downwind, sup, parawing, pump, prone carbon · 2026

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest, the GONG Veloce HDW V3 L, is already drawn over it. Select a numbered wing to draw it — up to three at a time.

6Code Foils R Series Front Wing 1075Rno outlineSpecs · table ↓

Unifoil Quest 160 · 1,175 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ GONG Veloce HDW V3 L · 1,180 mm

The Quest runs 3 sizes, 709–1,032 cm², and holds its proportions across the range: every size publishes an aspect ratio within 5% of the others.

Its 1,175 mm span is 23% wider than typical for the area — the median across the 130 current wings within 10% of its size is 956 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the Unifoil Quest 160, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
GONG	Veloce HDW V3 L	1,050	+1.7%	13.30	-0.7%	1,180	Very high aspect
GONG	Veloce DW V3 Atmo L	1,050	+1.7%	14.10	+5.2%	1,220	Very high aspect
GONG	Veloce Light Wind (LW) V3 Atmo L	1,050	+1.7%	12.70	-5.2%	1,150	Very high aspect
Axis	Fireball ULTRA 1160	996	-3.5%	13.52	+0.9%	1,160	Very high aspect
Armstrong	UHA (Ultra High Aspect) UHA1070	1,070	+3.7%	12.60	-6.0%	1,161	Very high aspect
Code Foils	R Series Front Wing 1075R	1,075	+4.2%	13.00	-3.0%	1,180	Very high aspect
Sabfoil	Leviathan PRO 1160	1,083	+4.9%	12.42	-7.3%	1,160	Very high aspect

Specifications

Every figure is Unifoil's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	Quest
Size	Quest 160
Area, cm²	1,032
Area basis	unknown
Span, mm	1,175
Chord, mm	113
Aspect ratio	13.40
Band	Very high aspect
Brand’s category	Downwind
Disciplines	downwind, sup, parawing, pump, prone
Construction	carbon
Model year	2026
Source	manufacturer

The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
