Takoon Pump One Front Wing 2000

2,000area, cm²
1,360span, mm
9.25aspect ratio
Midaspect · AR 8.5 – 9.5

Family Pump One Chord 197 mm Brand’s category Pump / dock Disciplines pump

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest with a traced outline, the GONG Trail V3 XL (#3), is already drawn over it. Select a numbered wing to draw it — up to three at a time.

1ENSIS STRIDE Front Wing 2050no outline2North Sonar P2050no outlineSpecs · table ↓

Takoon Pump One Front Wing 2000 · 1,360 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ GONG Trail V3 XL · 1,350 mm

The Pump One Front Wing runs 3 sizes, 1,600–2,000 cm², and holds its proportions across the range: every size publishes an aspect ratio within 5% of the others.

Its 1,360 mm span is 5% wider than typical for the area — the median across the 50 current wings within 10% of its size is 1,295 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the Takoon Pump One Front Wing 2000, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
ENSIS	STRIDE Front Wing 2050	2,050	+2.5%	9.50	+2.7%	1,400	Mid aspect
North	Sonar P2050	2,050	+2.5%	9.60	+3.8%	1,400	High aspect
GONG	Trail V3 XL	1,940	-3.0%	9.40	+1.6%	1,350	Mid aspect
Axis	PNG (Pump and Glide) 1310	2,080	+4.0%	8.53	-7.8%	1,310	Mid aspect
Duotone	Amp 2.0 SLS 2100	2,100	+5.0%	9.70	+4.9%	1,430	High aspect
RRD	Universal Moonfish Front Wing Y30 1900	1,900	-5.0%	9.60	+3.8%	1,350	High aspect

Specifications

Every figure is Takoon's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	Pump One
Size	2000
Area, cm²	2,000
Area basis	unknown
Span, mm	1,360
Chord, mm	197
Aspect ratio	9.25
Band	Mid aspect
Brand’s category	Pump / dock
Disciplines	pump
Construction	—
Model year	—
Source	manufacturer

The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
