Duotone Aero Glide SLS 905: a legacy wing, no longer in Duotone's current range. 905 cm², 920 mm span, aspect ratio 9.40. The current wings that match it within ±5% area and ±8% aspect ratio, from Duotone's own published specifications.
Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a match inside the area tolerance may be comparing unlike figures.
| Brand | Wing | Area cm² | Δ area | Aspect ratio | Δ AR | Span mm | Band |
|---|---|---|---|---|---|---|---|
| RRD | Flying Fish Front Wing Y30 900 | 900 | -0.6% | 9.40 | +0.0% | 910 | C3 Mid aspect |
| ENSIS | FLOW ACE Front Wing 900 | 900 | -0.6% | 9.50 | +1.1% | 925 | C3 Mid aspect |
| AFS | Pure Fuselink Foil (monobloc front wing + fuselage) Pure 900 | 900 | -0.6% | 9.20 | -2.1% | 900 | C3 Mid aspect |
| Unifoil | Evolution 135 Evolution 135 | 871 | -3.8% | 9.40 | +0.0% | 903 | C3 Mid aspect |
| F-One | EAGLE HM Carbon EAGLE 890 | 890 | -1.7% | 9.60 | +2.1% | 925 | C4 High aspect |
| Unifoil | Progression 140 Progression 140 | 903 | -0.2% | 8.90 | -5.3% | 898 | C3 Mid aspect |
| Armstrong | HA (High Aspect) HA880 | 880 | -2.8% | 9.68 | +3.0% | 923 | C4 High aspect |
| GONG | Ypra Slalom V3 Atmo L | 900 | -0.6% | 8.90 | -5.3% | 880 | C3 Mid aspect |
| Axis | Surge Surge 950 | 949 | +4.9% | 9.52 | +1.3% | 950 | C4 High aspect |
| Axis | ART v2 ART v2 939 | 900 | -0.6% | 10.00 | +6.4% | 940 | C4 High aspect |
| Omen | Agent 900 Agent 900 | 900 | -0.6% | 10.10 | +7.4% | 954 | C4 High aspect |
| GONG | Fluid V3 Atmo M | 910 | +0.6% | 8.70 | -7.4% | 890 | C3 Mid aspect |
| Slingshot | One-Lock Glide 925 | 925 | +2.2% | 8.80 | -6.4% | 899 | C3 Mid aspect |
| GONG | Veloce V3 Atmo M | 890 | -1.7% | 10.10 | +7.4% | 950 | C4 High aspect |
| North | Sonar SF930 SF930 | 930 | +2.8% | 8.80 | -6.4% | 900 | C3 Mid aspect |
| AFS | Silk V2 Front Wing Silk 950 | 950 | +5.0% | 9.00 | -4.3% | 925 | C3 Mid aspect |
| Family | Aero Glide |
|---|---|
| Size | 905 |
| Area, cm² | 905 |
| Area basis | unknown |
| Span, mm | 920 |
| Chord, mm | — |
| Aspect ratio | 9.40 |
| Band | C3 Mid aspect |
| Brand files it under | Glide / high aspect |
| Disciplines | wing, downwind, pump |
| Construction | SLS |
| Model year | 2024 |
| Source | manufacturer |
The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.
See Duotone on the plot →Data current to August 2026. Fast Bobby is the researcher, never the reviewer: every figure above is the manufacturer's published claim, converted to comparable units, and nothing here is a riding impression.
