Duotone Crest D/LAB 1050

1,050area, cm²
960span, mm
8.80aspect ratio
Midaspect · AR 8.5 – 9.5

Family Crest Brand’s category Surf / carve Disciplines wing, prone, tow D/LAB · 2026

Drawn to scale · the closest current wings

true relative scale

The closest current wings from other brands — every one within ±5% of area and ±8% of aspect ratio, ranked closest first. The closest, the AFS Silk V2 Front Wing 1050, is already drawn over it. Select a numbered wing to draw it — up to three at a time.

8Code Foils X Series Front Wing 1085Xno outline9Unifoil Aggression 170no outline10Unifoil Progression 170no outline13Unifoil Evolution 155no outline16ENSIS FLOW ACE Front Wing 1080no outline17F-One EAGLE HM Carbon 1090no outlineSpecs · table ↓

Duotone Crest D/LAB 1050 · 960 mm span · traced from the manufacturer’s plan view · drawn nose-up, wings aligned on the mid-point of the root chord (the dotted line). ▬ AFS Silk V2 Front Wing 1050 · 972 mm

The Crest D/LAB runs 6 sizes, 550–1,200 cm²; aspect ratio moves 8.6–9.3 across the range.

Its 960 mm span is typical for the area: the median across the 131 current wings within 10% of its size is 970 mm.

Closest wings from other brands

Projected and flat area run 3–8% apart. A marked area is one whose brand does not state which it publishes, so a comparison inside the area tolerance may be comparing unlike figures.

Current wings from other brands within ±5% of area and ±8% of aspect ratio of the Duotone Crest D/LAB 1050, closest first.
Brand	Wing	Area cm²	Δ area	Aspect ratio	Δ AR	Span mm	Band
AFS	Silk V2 Front Wing 1050	1,050	+0.0%	9.00	+2.3%	972	Mid aspect
Takoon	Flare Front Wing 1050	1,050	+0.0%	8.60	-2.3%	950	Mid aspect
Naish	Jet HA Front Wing 1040	1,040	-1.0%	9.20	+4.5%	980	Mid aspect
GONG	Curve H V3 FG L	1,070	+1.9%	8.40	-4.5%	950	Mid-low aspect
RRD	Flying Fish Front Wing Y30 1050	1,050	+0.0%	9.30	+5.7%	990	Mid aspect
GONG	Fluid H V3 FG L	1,010	-3.8%	8.40	-4.5%	920	Mid-low aspect
GONG	Fluid V3 Atmo L (Team / Carbon HM)	1,010	-3.8%	8.70	-1.1%	940	Mid aspect
Code Foils	X Series Front Wing 1085X	1,085	+3.3%	8.20	-6.8%	940	Mid-low aspect
Unifoil	Aggression 170	1,096	+4.4%	8.20	-6.8%	950	Mid-low aspect
Unifoil	Progression 170	1,097	+4.5%	8.30	-5.7%	953	Mid-low aspect
Naish	Siren MA Front Wing 1000	1,000	-4.8%	8.54	-3.0%	922	Mid aspect
Sabfoil	909 Balz Muller Limited Müller	1,000	-4.8%	8.26	-6.1%	909	Mid-low aspect
Unifoil	Evolution 155	1,000	-4.8%	9.40	+6.8%	968	Mid aspect
Axis	Surge 1010	1,076	+2.5%	9.49	+7.8%	1,010	Mid aspect
Sabfoil	Blackbird 905 Balz Muller Signature	998	-5.0%	8.30	-5.7%	905	Mid-low aspect
ENSIS	FLOW ACE Front Wing 1080	1,080	+2.9%	9.50	+8.0%	1,013	Mid aspect
F-One	EAGLE HM Carbon 1090	1,090	+3.8%	9.50	+8.0%	1,020	Mid aspect
Cabrinha	Fusion H-Series MkII H1000	1,000	-4.8%	8.10	-8.0%	900	Mid-low aspect
Cabrinha	Whippit 1000	1,000	-4.8%	8.10	-8.0%	900	Mid-low aspect

Specifications

Every figure is Duotone's own, read from the source linked in the last row, converted to area in cm² and span in mm.
Family	Crest
Size	1050
Area, cm²	1,050
Area basis	unknown
Span, mm	960
Chord, mm	—
Aspect ratio	8.80
Band	Mid aspect
Brand’s category	Surf / carve
Disciplines	wing, prone, tow
Construction	D/LAB
Model year	2026
Source	manufacturer

The brand's published aspect ratio agrees with its own span and area (span² ÷ area) to within 5%, so the figure is confirmed.

Data current to August 2026. Every figure above is the manufacturer's published claim, converted to comparable units.
